Marantz PM7000N

Channels 2

Current Feedback Topology Yes

Full balanced circuitry architecture No

Double Mono Power Amp construction No

Phono EQ: Standard / Marantz Musical / Marantz Musical Premium Yes / No / No

Digital in: USB-B / optical / coaxial / USB-A No / 2 / 1 / 1

Sample Rate digital In 192 kHz / 24-bit

USB-A: DSD / WAV / FLAC / AIFF / ALAC <=5.6 / 192 / 192 / No / 192

USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6 No

USB-B PCM sample rate No

DAC chip AK4490

Asynchronous mode rear USB No

Bit-perfect transmission No

Ground isolator for DAC Mode operation No

Tuner: DAB / DAB+ / FM (RDS) No

Bluetooth / aptX / NFC Yes / No / No

Streaming audio from PC Yes

Wi-Fi / Wired LAN Yes / Yes

Internet radio Yes

AirPlay 2 Yes

Windows Play to Yes

Spotify Connect* / Tidal* / Deezer* / others * Yes / Yes / Yes / Yes

Amazon Prime Music* / Pandora* Yes / Yes

HEOS Multiroom and Streaming Yes

Voice Control - Works with Amazon Alexa Yes

Voice Control - Google Assist / Apple Siri Yes

Voice Control - Microphone built-in No

DSD-Audio network streaming Yes

Lossy formats: MP3 / WMA / AAC Yes / Yes / Yes

Lossless formats: DSD / FLAC HD 192/24 / ALAC 96/24 / WAV 192/24 / AIFF Yes / Yes / Yes / Yes / No

Gapless Playback Yes

Remote APP: iDevice / Android Yes / Yes

Analog Mode No

HDAM version SA3, SA2

Power Transformer: Toroidal / El Yes / No

High Grade Audio Components Yes

Customised Components Yes

Symmetric PCB Layout Yes

Aluminium extrusion heat sink Yes

Copper Plated Chassis No

Tri Tone Control (Bass / Mid / Treble) No

Balance / Bass / Treble / Loudness Yes / Yes / Yes / No

Others

Marantz Musical Digital Filtering No

Linear Drive Power Supply Yes

Liniear volume control Yes

BI-AMP and Multichannel option No

Shottky diodes Yes

Input buffer amp (all inputs / CD only) No / No

System block shielding: Copper / metal / none No / No / Yes

Double Layer Bottom Plate No

Low Noise OELD display Yes

Low noise LCD display No

Source Direct Yes

Power Amp direct No

5mm aluminium top plate No

Inputs/Outputs

Audio Inputs 4 Digital in: USB-B / optical / coaxial / USB-A No / 2 / 1 / 1

Phono Input: MM / MC Yes / No

Audio Outputs 1

Balanced In / Out No

Pre-out / Main-in subwoofer / No

Power Amp Direct IN No

HDMI: inputs / outputs No

Gold Plated Cinch Yes

Speaker A / B No

Speaker Terminals Marantz SPKT-1+

Number of terminals 2

D-Bus Yes

Floating Control Bus (3.5 mm mono jack x 2) No

Headphone Out Yes

Headphone Gain Control (low / mid / high) No
